mongodb admin 库中执行

use admin
db.createUser({
    user: "prometheus",
    pwd: "prometheus",
    roles: [
        { role: "read", db: "admin" },
        { role: "readAnyDatabase", db: "admin" },
        { role: "clusterMonitor", db: "admin" }
    ]
});

1

地址：  https://github.com/percona/mongodb_exporter

1

nohup  ./mongodb_exporter --mongodb.uri mongodb://root:heian@192.168.82.105:27017/admin --collect.database --collect.collection --collect.topmetrics  --collect.indexusage  --collect.connpoolstats --suppress.collectshardingstatus  &

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31

[root@prometheus-server exporter]# ./mongodb_exporter --help
usage: mongodb_exporter [<flags>]

exports various MongoDB metrics in Prometheus format.

Flags:
  -h, --help                   Show context-sensitive help (also try --help-long and --help-man).
      --web.auth-file=WEB.AUTH-FILE
                               Path to YAML file with server_user, server_password keys for HTTP Basic authentication (overrides HTTP_AUTH environment variable).
      --web.ssl-cert-file=WEB.SSL-CERT-FILE
                               Path to SSL certificate file.
      --web.ssl-key-file=WEB.SSL-KEY-FILE
                               Path to SSL key file.
      --web.listen-address=":9216"
                               Address to listen on for web interface and telemetry.
      --web.telemetry-path="/metrics"
                               Path under which to expose metrics.
      --collect.database       Enable collection of Database metrics
      --collect.collection     Enable collection of Collection metrics
      --collect.topmetrics     Enable collection of table top metrics
      --collect.indexusage     Enable collection of per index usage stats
      --collect.connpoolstats  Collect MongoDB connpoolstats
      --suppress.collectshardingstatus
                               Suppress the collection of Sharding Status
      --mongodb.uri=[mongodb://][user:pass@]host1[:port1][,host2[:port2],...][/database][?options]
                               MongoDB URI, format
      --test                   Check MongoDB connection, print buildInfo() information and exit.
      --version                Show application version.
      --log.level="info"       Only log messages with the given severity or above. Valid levels: [debug, info, warn, error, fatal]
      --log.format="logger:stderr"
                               Set the log target and format. Example: "logger:syslog?appname=bob&local=7" or "logger:stdout?json=true"

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22

配置启动服务
vim /usr/lib/systemd/system/mongodb_exporter.service
[Unit]
Description=mongodb_exporter
Documentation=https://github.com/percona/mongodb_exporter
After=network.target

[Service]
Type=simple
User=prometheus
Environment="MONGODB_URI=mongodb://mongodb_exporter:123456@localhost:27017"
ExecStart=/usr/local/bin/mongodb_exporter --log.level=error \
  --collect.database \
  --collect.collection \
  --collect.topmetrics \
  --collect.indexusage \
  --collect.connpoolstats

Restart=on-failure

[Install]
WantedBy=multi-user.target

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13

  - job_name: 'mongo_cluster'
    file_sd_configs:
      - files: ['/usr/local/prometheus/sd_config/mongo_cluster.yaml']
        refresh_interval: 5s
root:/usr/local/prometheus# cat /usr/local/prometheus/sd_config/mongo_cluster.yaml
- targets:
        - "192.168.88.140:9216"
        - "192.168.88.141:9216"
        - "192.168.88.142:9216"
  labels:
          project: mongo
          unitname: "Mongodb_exporter"
          service: mongo
